2155QIMAX 1700 ft-lbs Pistol Grip Air Impact Wrench 1” Square Drive Ingersoll Rand. Actuation/Throttle Type/Switch Type: Trigger Air Consumption @ Load (cfm): 32 cfm Air Consumption @ Load (l/min): 906 l/min Air Inlet: 3/8” NPT Air Pressure (PSI): 90
The 2155QIMAX 1700 ft-lbs Pistol Grip Air Impact Wrench 1” Square Drive Ingersoll Rand delivers incredible performance and industrial-grade durability in an impact wrench. Plus, its efficient air motor reduces air consumption to save you money. Perfect for the most demanding applications, such as truck and bus service, construction and agricultural equipment maintenance, as well as the MRO market.
1350 ft-lbs of maximum reverse torque from a tool that weighs just 7.4 lbs and is compact enough to access tight spaces. Finely tuned twin hammer impact mechanism and 7-vane motor deliver more torque, durability, and efficiency. An air motor thats 16% more efficient than its predecessor and an easy-to-clean inlet screen means less downtime, better tool performance, and less money spent on compressed air. The anodized end plate and steel hammer case is designed to be strong and durable, to protect the interior components of the air impact wrench.
This impact wrench is built to last and designed to withstand tough use in rugged environments. Feather-touch trigger, patented one-hand forward/reverse control and enhanced socket retention provides maximum control and easy operation of this air impact wrench. Easier access to grease fittings – for quicker maintenance and less downtime. Optimized for the vehicle repair industry, body shops, general industrial use, MRO, rail, heavy machinery, oil and gas, shipbuilding, construction, and facility maintenance. Optimized air flow for maximized performance when using this pneumatic impact wrench.
The 2155QIMAX 1700 ft-lbs Pistol Grip Air Impact Wrench 1” Square Drive Ingersoll Rand is backed by a 2-year warranty for peace of mind.
| Part Number | 2155QIMAX |
|---|---|
| Actuation/Throttle/Switch | Trigger |
| Air Cons. @ Load (cfm) | 32 cfm |
| Air Cons. @ Load (l/min) | 906 l/min |
| Air Inlet | 3/8'' NPT |
| Air Pressure (PSI) | 90 PSI |
| Anvil Length | Standard |
| Average Air Cons. (cfm) | 8.5 cfm |
| Average Air Cons. (l/min) | 241 l/min |
| Blows per Min | 1150 BPM |
| Color | Grey |
| Configuration/Handle Type | Pistol Grip |
| Drive Size | 1'' |
| Drive Type | Square |
| Duty Rating | Industrial Duty |
| End Plates | Aluminum with Steel Wear Plate |
| Exhaust Location | Bottom |
| Free Spd Sound Prssr/Pwr | 91.1 / 102.1 |
| Hammer Case | Steel |
| Handle Material | Composite |
| Impact Mechanism | Twin Hammer |
| Impact Sound Prss/Pwr Db(A) | 96.3 / 107.3 |
| Max Bolt Diameter | 1'' |
| Max Free Speed (rpm) | 7000RPM |
| Max Pressure | 6.2 bar |
| Max torque | 1350 ft-lbs / 16197 in-lbs / 1830 Nm |
| Min. Hose Size | 1/2'' |
| Motor | Reverse Bias |
| Number of Power Settings | 4 |
| Nut-busting/Breakaway Trq | 1700 ft-lbs / 20401 in-lbs / 2305 Nm |
| Power Source | Air Powered |
| Pwr-Wgt Ratio (Torque/Wgt) | 182.4 ft-lbs/lbs |
| Product Height | 8.1'' / 206mm |
| Product Length | 8.5'' / 216mm |
| Product Weight | 7.4lbs / 3.36kg |
| Product Width | 3.3'' / 84mm |
| Quiet Tool | Yes |
| Rec. Forward Torque Range | 900 ft-lbs / 10798 in-lbs / 1220 Nm |
| Retainer Type | Friction Ring and Thru-hole |
| Side to Center Distance(in) | 1.7'' / 43mm |
| Standards/Certifications | Cagi B186, Iso 11148-6, Iso 15744, Iso 28927-2 |
| Tool Type | Full-size |
| UPC | 663023097183 |
| Vanes | 7 |
| Vibration Level (m/s2) | 8.7m/s2 |
| Warranty | 2-year |
